KJT-FQ Micro Photoelectric Sensor
- Product Mode：KJT-FQ
- Minimum detection object：Opaque objects: 1mm
- Light source (luminescence wavelength)：Infrared LED (680nm)
- Response time：0.5ms max
- Accessories：M2x8 screws, spring washers, flat washers
KJT photoelectric switch is through the change of light intensity into an electrical signal to achieve control.KJT photoelectric switch product range is complete, diffuse reflection type, mirror reflection type, counter-reflective type, cylindrical, square, groove type, relay output, etc. KJT standard photoelectric switch product range is complete, diffuse reflection type, mirror reflection type, counter-reflective type, long-distance type, intelligent type, relay output type, anti-interference, stable performance, comprehensive your needs. Stable, fully meet your needs.
Product type | KJT-FQ | ||
| Detection distance | 150mm/300mm | ||
| Minimum Detected Objects | Opaque Objects：1 mm | ||
| Shell material | denatured polyaromatic resin (DPR) | ||
| Supply Voltage | 12~24V DC pulsation (P-P) ±10% max | ||
| Consumption Current | Light Receiver:20mA, Light Thrower:10mA | ||
| Response time | 0.5ms max | ||
| Light source | Infrared light (680nm) | ||
| Load supply voltage | 30V DC max. | ||
| Load supply current | 50mA max. | ||
| Insulation resistance | 200mΩ min. (DC500V) | ||
| Withstand voltage | AC1,000V 50/60Hz min | ||
| Vibrations | 10-500Hz Bi-amplitude 3 mmX, Y, Z 2h in each direction | ||
| Impact | 500m/s²X、Y、Z 3 times in each direction. | ||
| Short circuit protection | Yes | ||
| Operating temperature | -25°C- 55°C | ||
| Environmental humidity | 35 to 85% RH | ||
| Suitable for intensity light | ≤5.000Lux max. | ||
| Protection level | IP67 | ||
| Accessories | M2*8 screws, spring washers, flat washers | ||
