| Double disconnect mechanical function | INO+INC force disconnect buckle action forced disconnect fast movement |
| Rated voltage/current Rated voltage/current | 10(4)A, 125, 250VAC/6(2)A, 380VAC inductive load, residual φ=0.4 |
| contact resistance contact resistance | Initial <10mΩ, tested <30mΩ |
| Insulation resistance | 500mΩ minimum at 100VDC |
| Dielectric strength | AC 200VAC/minute between bare metal/terminal, ground and counter pole |
| Electrical life | 500,000 at 10A 250VAC resistive |
| Mechanical life | 20,000,000 |
| operating speed | 120 /Minute |
| Waterproof Or dustproof ability | IP66(Pressure water column level) |
| rising temperature | At rated voltage/current, up to 30°C over the entire ambient temperature range |
| standards | CENELEC EN 50041，EN 50047，IEC 337-1，VDE 0660 |
| operating temperature | -25°C~+80°C |
| storage temperature | -25°C~+80°C |
| humidity | Maximum 95° relative humidity (no dew) |
| Impact coefficientImpact resistance | Free position 10G Overtravel position 30G |
| Vibration frequency | MAX 55Hz |
| Terminal screw torque | 6-8kg method-cm |
| Other screw torque | Cover 12-14 kg ft cm/head 8-9 kg ft cm/installed 50-60 kg ft/cm |
| Copper wire size | φ2 max |
| Cable diameter size | φ9 Maximum value (if using cable IP 66 φ8-9) |
