| Operating Voltage | 15...30VDC |
| Installation method | ---------- |
| Detection distance | 10...100mm |
| product specifications | M18*1*65 |
| output method | 0~10V ，4-20mA |
| working frequency | 80Hz |
| Current consumption | ≤20mA |
| output signal | PNP Analog |
| Switch point offset | ≤±10% |
| Load current | ≧4.7KΩ（Voltage output）≤470Ω（Current output） |
| lag | 3...15% |
| Repeat accuracy | ≤1% |
| LED display | ------------ |
| Protect | Short circuit, reverse polarity, overload protection |
| Operating temperature | -10...50℃ |
| temperature drift | <±10% |
| Protection level | IP67 |
| Shell material | brass nickel plated |
| Detection surface material | PBT |
| Wiring | Cable 2 meters, outer diameter φ4.8mm |
