Intelligent pressure controller is an intelligent digital display pressure measurement and control product which integrates pressure measurement, display, output and control. The product is all-electronic structure, the front-end with Geli membrane oil-filled piezoresistive pressure sensors, by the high-precision A/D conversion, by the microprocessor algorithm processing, on-site display, and the output of - road analog and four switching quantities.
The intelligent digital pressure controller is flexible in use, simple in operation, easy in debugging, safe and reliable. Widely used in hydropower, water, petroleum, chemical, machinery, hydraulic and other industries, the pressure of the fluid medium for on-site measurement display and control.
| Type | Product Description | |
| KJT - C | Digital electric contact pressure gauge | |
| output method | 101 | Single relay output |
| 102 | Dual Relay Outputs | |
| 103 | Three relay outputs | |
| 104 | Four relay outputs | |
| 2 | NO | |
| 3 | NO＋NC | |
| transformer output | 0 | No output |
| 2 | 4-20mA output | |
| Accuracy level | 1 | 1% |
| 2 | 0.5% | |
| process connection | A | 20*1.5 |
| B | G1/2 | |
| C | Other specify when ordering | |
| Power supply | A | AC220V power supply |
| W | DC24V power supply | |
| Measurement method | -100KPa-160MPa | Customer choice |
