KJTE-XT-560 Digital Thermometer
KJTE-XT-560 Digital Thermometer

KJTE-XT-560 Digital Thermometer

  • brand name:digital thermometer
  • model number:KJTE-XT-560
  • Temperature range:The default temperature range is -50-200℃, please contact customer service for quotation if you need other temperature range.
  • Product Diameter:140mm
  • Dial Diameter:110mm
  • Installation Diameter:111.5mm
  • Installation:Default thread is movable thread M27*2 (thread O.D. 27mm, pitch 2mm).
  • power supply:Default is 2 x 5 batteries
  • Display Color:Black digital display
  • Switched as standard:Switched as standard
  • material (that sth is made of):All 304 stainless steel (except metal hose)

1

Digital thermometer shape using all stainless steel 304 material, strong and beautiful and durable, the use of imported chip assembly, high stability, built-in 1 section of 5 batteries, micro-power consumption, low temperature drift, integrated circuits and liquid crystal display, without external power supply, the applicability of a new type of field temperature display instrument, is the traditional field pointer bimetallic, thermometer, now want to replace the product, widely used in electric power iron and steel all kinds of machinery and equipment supporting.


universal suffrageclarification
KJTE-XT-560
digital thermometer
output methodAradial direction
B
axis
clamshellAPlastic Engineering Housings
BStainless steel 304 housing
Accuracy Class11%
20.5%
process connectionA20*1.5
BG1/2
C27*2
DOther orders are specified
Power supply methodNbattery powered
Temperature range-50+200 ℃Customer Choice


4


11
