KJT wireless inclination sensor
- Input voltage：3.7VDC
- Working current：≤2.6mA
- Lithium battery capacity：3000mA
- Operating temperature：-40℃-80℃
- Working humidity：≤95%
- waterproof level：IP65
Detect the angle change of the sensor installation position relative to the horizontal position, send the data to the host in real time, and enter the monitoring platform for display. It adopts an integrated explosion-proof design, the sensor is built inside the transmitter, uses a built-in lithium battery, supports external power supply, and has an ultra-low power consumption design.
| Input voltage | 3.7VDC |
| Working current | ≤2.6mA |
| Lithium battery capacity | 3000mA |
| Theoretical charging time | 40days |
| Operating temperature | -40℃一85℃ |
| Working humidity | ≤95% |
| Wireless communication maximum distance | 300米 |
| waterproof level | IP65 |
| Measuring range | Biaxial plus or minus 70° |
| measurement accuracy | 0.1° |
Implementation standards
| serial number | Standard/document number | Standard/File Name | Remark |
| 1 | GB2423.1-89 | Basic Environmental Test Procedures for Electrical and Electronic Products - Low Temperature Test | |
| 2 | GB2423.2-89 | Basic Environmental Test Procedures for Electrical and Electronic Products - High Temperature Test | |
| 3 | GB2423.17 | Basic environmental testing procedures for electrical and electronic products-salt spray test |
